MiWire RouDem is a combination of an auto-rotating, directional antenna and a modem that provides Internet connection via the mobile network. The RouDem is a plug-n-play solution and will automatically point the antenna in the direction of the best operator base station.
The connection to the Internet is obtained via a data SIM card, which you insert into the RouDem. The RouDem is prepared for outdoor installation at the highest spot possible on a standard antenna pole. Additionally, the RouDem has an integrated WiFi router and battery giving over 8 hours of operation.
Find out what it takes to get online with MiWire RouDem.
RouDem is a wireless broadband solution and therefore for the RouDem to receive signal you must insert a SIM card with data. The data subscription is a side purchase to the RouDem. To gain the best speed with RouDem it is essential to choose a data subscription from that operator who has the best coverage conditions on your location. Read more about the data subscriptions in our FAQ.
The package content includes 10 m cable. Depending on the installation scenario it might be necessary to purchase another cable with the suitable length for the intended installation. Download the product sheet to get an overview of the system configuration.
Cable specifications:
Network cable type: Cat6 or above, UV- and water resistant, shielded, grounded.
Connector 1 & 2: RJ45 (male)
The RouDem is designed with a mounting bracket that interfaces to a pole of Ø38mm/1.5” (outer diameter). The mounting should take place at the highest spot possible and where possible with a good all-round view.
In some cases, the WiFi signal from the RouDem is not strong enough to cover the needs if the WiFi signal must pass through walls and other signal noise reducing items. You can connect the RouDem to your existing WiFi system or a switch via the LAN port in the power supply. In that way you can easily distribute the WiFi signal to where it is needed.
MiWire RouDem is a premium plug-n-play wireless broadband solution for users who wants to gain better reach and higher speed based on the LTE network. The RouDem performs best at the edge of the network coverage. Depending on where you are, or which data subscription you have, you will experience different speeds. The RouDem can be used as a fixed installation as well as a mobile solution. Live or work in rural area with poor internet access? Always on the move for holiday or work? Then this is the solution for you.
MiWire’s solutions contain patented, auto-rotating, directional antennas that points to the most optimal operator base station, controlled by our embedded software algorithm. MiWire’s intelligent, high-gain antennas not only automatically locate the best operator base station. Our solutions also scan and memorize the network infrastructure through an advanced, patented software algorithm to ensure maximum data speed, even when changes in the network infrastructure is made.
We have developed plug-n-play solutions in which installers do not need to have knowledge of the network infrastructure in order to install. MiWire ensures high performance data speed – wherever you are.
LTE-Advanced CAT6 with 2×CA and 2×2 MIMO
Long-range directional antenna with automatic rotation for optimal signal
Built-in Wi-Fi (2.4 GHz, up to 300 m coverage)
Integrated battery for up to 8 hours operation
Rugged IP55 dust- and spray-proof
Web-based management with advanced network tools
1 × MiWire RouDem 4G (CAT6)
1 × Mounting bracket
1 × PoE adapter
1 × 10 m Ethernet cable
1 × Back plate
2 × Keys (Unbraco 4 & Torx 10)
5 × Screws
1 × User guide
1 × Privacy policy
Antenna: Directional (3–10 dBi @ 800–2700 MHz), omnidirectional (3–4.5 dBi)
Rotation: Infinite rotary motor for automatic pointing
LAN: 1 × RJ-45 (10/100 Mbps)
SIM: 1 × Micro-SIM 3FF slot
Wi-Fi: IEEE 802.11 b/g/n (2.4 GHz, 300 Mbps, up to 300 m coverage)
Battery: Lithium-ion, up to 8 hours operation
Power: Passive PoE 22–48V, max. 500 mA, 24W AC/DC adapter
Environmental: IP55, operational temp. -20°C to 80°C
4G LTE-FDD/TDD: B1, B3, B5, B7, B8, B20, B28, B32, B38, B40, B41
3G WCDMA: B1, B3, B5, B8
MiWire RouDem delivers stable, high-speed internet where conventional equipment falls short. It’s ideal for both permanent and temporary installations that demand long range, flexibility, and robust performance.
Remote Homes & Cabins: Reliable internet access in areas without fixed broadband.
Mobile Work Units: Stable connectivity for service and maintenance teams in the field.
Emergency & Rescue Units: Rapid deployment of internet during response operations or emergencies.
Events & Temporary Sites: Provides network coverage for festivals, construction sites, and sports events.
5G NR, LTE-A & 3G global coverage
Long-range directional antenna with automatic rotation for optimal signal
Built-in Wi-Fi 5 (2.4 GHz & 5 GHz)
Integrated battery for minimum 1 hour operation without external power
Rugged IP55 dust- and spray-proof
Web-based management and advanced network tools
1 × MiWire RouDem 5G
1 × Mounting bracket
1 × PoE adapter
1 × 10 m Ethernet cable
1 × Back plate
2 × Keys (Unbraco 4 & Torx 10)
5 × Screws
1 × User guide
1 × Privacy policy
Antenna: Directional (0.7–8 GHz, 3–11 dBi gain), omnidirectional options
Rotation: Infinite rotary motor for automatic pointing
LAN: 1 × RJ-45 (10/100/1000 Mbps)
SIM: 1 × Micro-SIM 3FF slot + eSIM (cannot be used simultaneously)
Wi-Fi: IEEE 802.11 a/b/g/n/ac Wave 2 (400 Mbps @ 2.4 GHz, 866 Mbps @ 5 GHz)
Battery: Lithium-ion, min. 1 hour operation
Power: PoE 802.3af, 48V, max. 500 mA, 24W AC/DC adapter
Environmental: IP55, operational temp. -20°C to 80°C
5G NR NSA & SA: Wide band support incl. n1, n2, n3, n7, n20, n28, n38, n40, n41, n48, n66, n70, n77, n78, n79
4G LTE-FDD/TDD: B1, B2, B3, B7, B20, B28, B38, B40, B41, B42, B43, B48, B66
3G WCDMA: B1, B2, B4, B5, B8, B19
GNSS: L1 & L5 bands
MiWire RouDem delivers stable, high-speed internet where conventional equipment falls short. It’s ideal for both permanent and temporary installations that demand long range, flexibility, and robust performance.
Remote Homes & Cabins: Reliable internet access in areas without fixed broadband.
Mobile Work Units: Stable connectivity for service and maintenance teams in the field.
Emergency & Rescue Units: Rapid deployment of internet during response operations or emergencies.
Events & Temporary Sites: Provides network coverage for festivals, construction sites, and sports events.
1) Select and test the location
Before final installation, test the RouDem outdoors at the highest point and as close as possible to the planned permanent location. For performance testing, connect the antenna directly to a computer with the Ethernet cable and run a speed test. The built-in battery allows testing without the power supply; if the battery is empty, connect the computer to the LAN output on the power supply instead.
3) Mount the unit
Install the RouDem horizontally on a Ø38 mm / 1.5" pole using the supplied mounting bracket. Ensure it has a clear all-round view and is positioned away from interference sources.
4) Route the cable
Use high-quality, shielded, and weather-resistant Ethernet cable for the connection between the antenna and the power supply or network equipment. Avoid running the cable alongside high-interference electrical lines.
5) Power up
Connect the Ethernet cable to the PoE adapter or power supply, then plug into AC power. The RouDem will power on automatically.
6) Connect and configure
Access the RouDem via Wi-Fi or Ethernet and open the web interface to adjust settings if needed, such as APN configuration, or to calibrate the compass.
7) Secure and finalize installation
Once testing and configuration are complete, secure all components, ensure weather seals are in place, and register the product for service and support.
Contact us for more information.
